Quadruplex Service Drop Cable

Tags : overhead quadruplex service drop cable, aluminum service drop cable,quadruplex ABC cable

Summary: Quadruplex service drop cable are constructed with three aluminum conductors,black extruded cross-linked polyethylene insulation, and a bare aluminum neutral.

Description

Zhenglan Cable Technology Co., Ltd

Quadruplex service drop cable Construction:

constructed with three aluminum conductors, black extruded cross-linked polyethylene insulation, and a bare aluminum neutral.

Conductors: concentrically stranded, compressed 1350-H19 aluminum.

Insulation: Insulated with either polyethylene or crosslinked polyethylene (XLP).

Neutral messengers: concentrically stranded 6201, AAC, or ACSR.

Core identification: Conductors are manufactured with ridges for phase identification (one conductor one ridge, one conductor two ridges, one conductor plain.)

Quadruplex service drop cable reference standards:

B-230 Aluminum Wire, 1350-H19 for Electrical Purposes

• B-231 Aluminum Conductors, Concentric-Lay-Stranded

• B-232 Aluminum Conductors, Concentric-Lay-Stranded,

 Coated Steel Reinforced (ACSR)

• B-399 Concentric-Lay-Stranded, 6201-T81 Aluminum Alloy Conductors

• B-901 Compressed Round Stranded Aluminum Conductors Using Single

 Input Wire

• ANSI/ICEA S-76-474

Quadruplex service drop cable application:

Used to supply 3 phase power, usually from a pole mounted transformer or secondary power line to the user’s service head where connection to the service entrance cable is made.

Quadruplex service drop cable features:

The black extruded cross-linked polyethylene insulation can protect the cable from temperatures as high as 90°C. The XLPE insulation also ensures this service drop wire is protected against a variety of outside forces including weather, abrasion, chemicals, cutting, and tearing. This allows for continued use of triplex wire in various harsh outdoor environments.

Specifications

Quadruplex service drop cable technical parameters

Notes:

Code words for XLPE insulated products are formed by adding "XLPE" to the conventional polyethylene code words above (e.g.- Pica/XLPE).

Ampacity figures for black insulation only. Based on conductor temperature of 75 ºC for polyethylene insulated conductors, 90 ºC for XLPE insulated conductors, ambient temperature of 40 ºC 2 ft./sec. wind in sun.

Code Word

Phase Conductor

Bare Neutral Messenger

Weight Per 1000 ft.(lbs.)

Allowable Ampacities



Size (AWG or kcmil)

Strand- ing

Insul. Thick. (mils)

Equiv. Dia. (AWG)

Size(kcmil)

Strand- ing

Rated Strength (lbs).

XLP

POLY

XLP

POLY

6201 ALLOY NEUTRAL-MESSENGER

Bay

6

1

45

6

30.58

7

1110

137

137

75

60

French Coach

6

7

45

6

30.58

7

1110

146

146

75

60

German Coach

4

1

45

4

48.69

7

1760

205

205

100

80

Arabian

4

7

45

4

48.69

7

1760

217

217

100

80

Belgian

2

7

45

2

77.47

7

2800

328

328

135

105

Shetland

1/0

19

60

1/0

123.3

7

4460

519

519

180

140

Thoroughbred

2/0

19

60

2/0

155.4

7

5390

639

639

205

160

Trotter

3/0

19

60

3/0

195.7

7

6790

789

789

235

185

Walking

4/0

19

60

4/0

246.9

7

8560

977

977

275

210

Code Word

Phase Conductor

Bare Neutral Messenger

Weight Per 1000 ft.(lbs.)

Allowable Ampacities



Size (AWG or kcmil)

Strand- ing

Insul. Thick. (mils)

Size (AWG or kcmil)

Strand- ing

Rated Strength (lbs).

XLP

POLY

XLP

POLY

AAC NEUTRAL-MESSENGER

Clydesdale

4

1

45

4

7

881

198

198

100

80

Pinto

4

7

45

4

7

881

211

211

100

80

Mustang

2

7

45

2

7

1350

318

318

135

105

Criollo

1/0

19

60

1/0

7

1990

503

503

180

140

Percheron

2/0

19

60

2/0

7

2510

619

619

205

160

Hanovarian

3/0

19

60

3/0

19

3310

764

764

235

185

Oldenburg

4/0

19

60

4/0

19

4020

945

945

275

210

Lippizaner

336.4

19

80

336.4

19

6146

1519

1519

370

280

Code Word

Phase Conductor

Bare Neutral Messenger

Weight Per 1000 ft.(lbs.)

Allowable Ampacities



Size (AWG or kcmil)

Strand- ing

Insul. Thick. (mils)

Size (AWG or kcmil)

Strand- ing

Rated Strength (lbs).

XLP

POLY

XLP

POLY

ACSR NEUTRAL-MESSENGER

Morochuca

6

1

45

6

(6)/(1)

1190

145

145

75

60

Chola

6

7

45

6

(6)/(1)

1190

153

153

75

60

Morgan

4

1

45

4

(6)/(1)

1860

217

217

100

80

Hackney

4

7

45

4

(6)/(1)

1860

229

229

100

80

Palomino

2

7

45

2

(6)/(1)

2850

347

347

135

105

Costena

1/0

19

60

1/0

(6)/(1)

4380

549

549

180

140

Grullo

2/0

19

60

2/0

(6)/(1)

5310

677

677

205

160

Suffolk

3/0

19

60

3/0

(6)/(1)

6620

837

837

235

185

Appaloosa

4/0

19

60

4/0

(6)/(1)

8350

1038

1038

275

210

Gelding

336.4

19

80

4/0

(6)/(1)

8350

1494

1494

370

280

Bronco

336.4

19

80

336.4

(18)/(1)

8680

1568

1568

370

280
