Cu(AL) XLPE SWA PVC LV armored Power Cable

Tags : 0.6-1kv armored aluminum cable,LV power Cables,LV XLPE Insulated power Cables,SWA armored power Cables

Summary: XLPE insulation SWA Armour. They are used for power networks, direct burial, outdoors, indoors and in cable ducts for electricity supply in low voltage installation system.

Description

Zhenglan Cable Technology Co., Ltd

Cu(AL)/XLPE/SWA/PVC LV armoured Cable construction:

Conductor:

Plain annealed stranded copper.

Insulation: XLPE (Cross linked polyethylene)

Bedding: PVC (Polyvinyl-Chloride)

Armour/Protection: SWA (Galvanised single wire armour)

Sheath/Jacket: PVC (Polyvinyl-Chloride)

Colour: Black

Voltage: 600/1000v

Operating temperature: Maximum 90°C. Minimum bending 0°C.

Technical data:

Operating voltage:1000 V

Test voltage: 3500V, according to IEC 60502

Operation temperature:–25°C to + 90°C

Permissible short therm: + 250°C

Bending radius:

1.5mm2 to 16mm2 - Fixed: 6 x overall diameter

25mm2 and above - Fixed: 8 x overall diameter

Cu(AL)/XLPE/SWA/PVC LV armoured Cable Application:Cu(AL)/XLPE/SWA/PVC LV armoured Cable is a aluminum or copper cable with XLPE insulation SWA Armour. They are used for power networks, direct burial, outdoors, indoors and in cable ducts for electricity supply in low voltage installation system

Standard:

BS5467: Electric cables. Thermosetting insulated, armoured cables for voltages of 600/1000V and 1900/3300V

IEC60502: Power cables with extruded insulation and their accessories for rated voltages from 1kV to 30kV

Flame Propagation Test to BS EN 60332-1-2 for single cable

Special version upon request:

Fire resistant version

LSZH sheath version

AWA,SWA,STA armoured version

PE sheath version

Core identification:

Two Core – Brown, Blue

Three Core – Brown, Black & Grey (Optional: Brown, Blue & Green/Yellow)

Four Core – Brown, Black, Grey & Blue (Optional: Brown, Black, Grey & Green/Yellow)

Five Core – Numbered Cores (Optional: Brown, Black, Grey, Blue + Green/Yellow)

Six Core and Above – Numbered Cores (optional numbered + Green and Yellow)

Specifications

Single core(Galvanized steel wire armoured)

nominal cross section (mm²)

OD(mm)

insulation nominal thickness (mm)

fine steel wire(mm)

current rating(A)









in ground

in Air

1.5

1.38

0.7

0.8

45

32

2.5

1.78

0.7

0.8

59

42

4

2.25

0.7

0.8

77

56

6

2.76

0.7

0.8

97

70

10

3.57

0.7

1.25

130

97

16

4.5

0.7

1.25

170

125

25

6.3

0.9

1.6

220

165

35

7.3

0.9

1.6

265

200

50

8.3

1

1.6

320

245

70

10

1.1

2

395

305

95

11.6

1.1

2

475

375

120

13

1.2

2

545

435

150

14.6

1.4

2.5

610

500

185

16.2

1.6

2.5

695

580

240

18.6

1.7

2.5

810

685

300

20

1.8

2.5

910

795

400

24.3

2

2.5

1050

930

Two cores(Galvanized steel wire armoured)

Nominal

Area

Approx

Conductor

Diameter

Nominal

Insulation

thickness

Nominal

bedding

thickness

Nominal

Steel Wire

dia.

Nominal

Sheath

thickness

Approx.

Overall

Diameter

Approx.

Weight

mm²

mm

mm

mm

mm

mm

mm

Kg/Km

2x1.5

1.38

0.7

1

0.9

1.8

13.5

360

2x2.5

1.76

0.7

1

0.9

1.8

14.5

405

2x4

2.25

0.7

1

0.9

1.8

15.8

470

2x6

2.76

0.7

1

0.9

1.8

17

505

2x10

4.0

0.7

1

1.25

1.8

19.3

900

2x16

5.0

0.7

1

1.25

1.8

21.2

950

2x25

6.3

0.9

1

1.6

1.8

24

1205

2x35

7.4

0.9

1

1.6

1.8

24.8

1800

2x50

8.8

1

1

1.6

1.8

26

1850

2x70

10.6

1.1

1

2

2

29

2335

2x95

12.4

1.1

1.2

2

2.1

33.2

3165

2x120

14.0

1.2

1.2

2

2.3

36.1

3750

2x150

15.5

1.4

1.2

2.5

2.3

39.3

4410

2x185

17.4

1.6

1.3

2.5

2.5

44.8

5710

2x240

20.3

1.7

1.4

2.5

2.7

53.5

7150

2x300

22.7

1.8

1.5

2.5

2.9

58

8565

2x400

25.4

2

1.6

2.5

3.1

63

10695







Three cores(Galvanized steel wire armoured)

Nominal

Area

Approx

Conductor

Diameter

Nominal

Insulation

thickness

Nominal

bedding

thickness

Nominal

Steel Wire

dia.

Nominal

Sheath

thickness

Approx.

Overall

Diameter

Approx.

Weight

mm²

mm

mm

mm

mm

mm

mm

Kg/km

3x1.5

1.38

0.7

1.2

0.9

1.8

15

380

3x2.5

1.76

0.7

1.2

0.9

1.8

15.5

400

3x4

2.25

0.7

1.2

0.9

1.8

16.5

460

3x6

2.76

0.7

1.2

0.9

1.8

18

540

3x10

4.0

0.7

1.2

0.9

1.8

19.5

750

3x16

5.0

0.7

1.2

1.25

1.8

22.5

1000

3x25

6.3

0.9

1.2

1.6

1.8

26

1510

3x35

7.4

0.9

1.2

1.6

1.8

28

1950

3x50

8.8

1.0

1.2

1.6

1.9

32

2350

3x70

10.6

1.1

1.2

2.0

2.0

35

3230

3x95

12.4

1.1

1.2

2 .0

2.1

39

4050

3x120

14.0

1.2

1.2

2.0

2.3

43

5230

3x150

15.5

1.4

1.4

2.5

2.4

47

6750

3x185

17.4

1.6

1.4

2.5

2.6

52

8230

3x240

20.3

1.7

1.5

2.5

2.7

59

10510

3x300

22.7

1.8

1.6

2.5

2.9

64

13210

3x400

25.4

2.0

1.6

2.5

3.2

74

16100

Three cores+1(Galvanized steel wire armoured)

Nominal

Cross

Approx

Conductor

Diameter

Nominal Insulation thickness

Nominal

bedding

thickness

Nominal

Steel

Wire dia.

Nominal

Sheath

thickness

Overall

Diameter

(Approx.)

Weight

of Cable

(Approx.)

mm²

(3)

mm

(1)

mm

(3)

mm

(1)

mm

mm

mm

mm

mm²

 mm

3x16/10

5

4

0.7

0.7

1

1.6

1.8

25.5

1550

3x25/16

6.3

5

0.9

0.7

1

1.6

1.8

27.5

2010

3x35/16

7.4

5

0.9

0.7

1

1.6

1.8

29

2375

3x50/25

8.8

6.3

1

0.9

1

1.6

2

33

3100

3x70/35

10.6

7.4

1.1

0.9

1.2

2

2.1

38

4290

3x95/50

12.4

8.8

1.1

1

1.2

2

2.3

43.5

5540

3x120/70

14

10.6

1.2

1.1

1.2

2

2.4

49

7150

3x150/70

15.5

10.6

1.4

1.1

1.4

2.5

2.5

52

8330

3x185/95

17.4

12.4

1.6

1.1

1.4

2.5

2.7

57.2

10110

3x240/120

20.3

14

1.7

1.2

1.6

2.5

3

64

12740

3x300/150

22.7

15.5

1.8

1.4

1.6

2.5

3

69.8

15430

3x400/185

25.4

17.4

2

1.6

1.6

3.15

3.3

78.6

19990

Four cores(Galvanized steel wire armoured)

Nominal

Area

Approx

Conductor

Diameter

Nominal

Insulation

thickness

Nominal

bedding

thickness

Nominal

Steel Wire

dia.

Nominal

Sheath

thickness

Approx.

Overall

Diameter

Approx.

Weight

mm²

mm

mm

mm

mm

mm

mm

Kg/km

4x1.5

1.6

0.7

1

0.9

1.8

15

415

4x2.5

2

0.7

1

0.9

1.8

17.5

490

4x4

2.6

0.7

1

0.9

1.8

19

600

4x6

3.1

0.7

1

0.9

1.8

20

730

4x10

4

0.7

1

1.25

1.8

23

970

4x16

5

0.7

1

1.6

1.8

26

1520

4x25

6.3

0.9

1

1.6

1.8

29

2010

4x35

7.4

0.9

1

1.6

1.9

31

2560

4x50

8.8

1

1

1.6

2.1

36

3350

4x70

10.6

1.1

1.2

2

2.2

40

4680

4x95

12.4

1.1

1.2

2

2.4

44

5710

4x120

14

1.2

1.4

2.5

2.5

50

7500

4x150

15.5

1.4

1.4

2.5

2.6

55

9010

4x185

17.4

1.6

1.4

2.5

2.8

61

10820

4x240

20.3

1.7

1.6

2.5

3.1

69

13630

4x300

22.7

1.8

1.6

2.5

3.2

75

16820

4x400

25.4

2

1.8

3.15

3.4

83

22230
